Master chip
|
ML307A
|
|
GPS chip
|
AT6558R
|
|
4G frequency band
|
LTE-FDD B1/B3/B5/B8 LTE-TDD B34/B38/B39/B40/B41
|
|
Operating voltage
|
2.5-3.5V DC
|
|
Product size (mm)
|
69*42*29
|
|
Product Net Weight
|
92.2G
|
|
Battery
|
Non-rechargeable battery: 3200mAh (2 PCS) / 4800mAh (3 PCS)
|
|
Indicator light
|
Blue light: Network light Green light: GPS light
|
|
Antenna
|
Built-in antenna: GPS ceramic and FPC
|
|
Maximum power output
|
LTE-FDD B1/B3/B5/B8:23dBm±2dBm LTE-TDD B34/B38/B39/B40/B41:23dBm±2dBm
|
|
Dynamic output range
|
-45～23dBm
|
|
Receive sensitivity
|
-98dBm
|
|
Maximum frequency error
|
±0.1ppm
|
|
Sensitivity
|
Cold start: -148 DBM Hot start: -156 DBM Recapture: -160 DBM Tracking: -162 DBM
|
|
TTFF
|
Cold start: 32 seconds on average
|
|
SIM Card
|
Nano SIM Open-top booth
|
