Master chip
|
ML307A
|
|
GPS chip
|
AT6558R
|
|
4G frequency band
|
LTE-FDD B1/B3/B5/B8 LTE-TDD B34/B38/B39/B40/B41
|
|
Operating voltage
|
External: 12/24V, internal battery: 3.4-4.2V DC
|
|
Product size (mm)
|
42*30*73
|
|
Product Net Weight
|
43.4g
|
|
Battery
|
Polymer battery 300 mAh
|
|
Indicator light
|
Red light: Power indicator
|
|
Antenna
|
Ceramic/onboard antenna and FPC
|
|
Start-up mode
|
Card boot
|
|
Maximum power output
|
LTE-FDD B1/B3/B5/B8:23dBm±2dBm LTE-TDD B34/B38/B39/B40/B41:23dBm±2dBm
|
|
Dynamic output range
|
-45～23dBm
|
|
Receive sensitivity
|
-98dBm
|
|
Maximum frequency error
|
±0.1ppm
|
|
Sensitivity
|
Cold start: -148 DBM Hot start: -156 DBM Recapture: -160 DBM Tracking: -162 DBM
|
|
TTFF
|
Cold start: 32 seconds on average
|
|
SIM Card
|
Nano Push
|
