4G Collar Cows GPS Tracker---[PetSecure20-4G ( Solar )]

No.PetSecure20-4G ( Solar )

PetSecure20-4G is a wearable livestock GPS tracker designed for robust outdoor use.
It supports 4G communication, GPS+BeiDou positioning, and features a large-capacity battery for long standby time.
With a durable metal structure, it is ideal for extreme environments and supports solar charging.
The device operates reliably in sub-zero temperatures and includes multiple alerts such as motion alarms, low battery warnings, and geofencing.

GET A QUOTE

Description

Products Description

Master chip	ML307A
GPS chip	AT6558R
4G frequency band	LTE-FDD B1/B3/B5/B8 LTE-TDD B34/B38/B39/B40/B41
Operating voltage	3.4-4.2V DC
Product size (mm)	1289350
Product Net Weight	545g
Battery	Polymer battery 12000 mAh
Indicator light	Blue: Data networking light Green: GPS light Red: charging
Antenna	Ceramic and FPC
Start-up mode	Hold down the power button for 3 seconds
Maximum power output	LTE-FDD B1/B3/B5/B8:23dBm±2dBm LTE-TDD B34/B38/B39/B40/B41:23dBm±2dBm
Dynamic output range	-45～23dBm
Receive sensitivity	-98dBm
Maximum frequency error	±0.1ppm
Sensitivity	Cold start: -148 DBM Hot start: -156 DBM Recapture: -160 DBM Tracking: -162 DBM
TTFF	Cold start: 32 seconds on average
SIM Card	Nano Push
