Master chip
|
A7670SA
|
|
4G frequency band
|
LTE-FDD B1/B2/B3/B4/B5/B7/B8/B28/B66 GSM：850/900/1800/1900 MHz
|
|
GPS chip
|
AT6558R
|
|
Operating voltage
|
9-90V DC
|
|
Product size (mm)
|
82*33*14.5
|
|
Product Net Weight
|
40.8g
|
|
Battery
|
Polymer battery 70 mAh
|
|
Battery operating temperature
|
Charge: 0 ~ +45℃, discharge: -10 ~ +60℃
|
|
indicator light
|
Blue: Network indicator Green: GPS indicator
|
|
Maximum power output
|
LTE-FDD B1/B2/B3/B4/B/5/B7/B8/B28/B66 GSM：850/900/1800/1900
|
|
Dynamic output range
|
-45～23dBm
|
|
Receive sensitivity
|
-98dBm
|
|
Maximum frequency error
|
±0.1ppm
|
|
Sensitivity
|
Cold start: -148 DBM Hot start: -156 DBM Recapture: -160 DBM Tracking: -162 DBM
|
|
TTFF
|
Cold start: 32 seconds on average
|
|
antrnna
|
GPS ceramic/RF antenna FPC
|
