Products Description
|
Master chip |
A7670SA |
|
4G frequency band |
LTE-FDD B1/B2/B3/B4/B5/B7/B8/B28/B66 GSM：850/900/1800/1900 MHz |
|
GPS chip |
AT6558R |
|
Operating voltage |
9-90V DC |
|
Product size (mm) |
82*33*14.5 |
|
Product Net Weight |
40.8g |
|
Battery |
Polymer battery 70 mAh |
|
Battery operating temperature |
Charge: 0 ~ +45℃, discharge: -10 ~ +60℃ |
|
indicator light |
Blue: Network indicator Green: GPS indicator |
|
Maximum power output |
LTE-FDD B1/B2/B3/B4/B/5/B7/B8/B28/B66 GSM：850/900/1800/1900 |
|
Dynamic output range |
-45～23dBm |
|
Receive sensitivity |
-98dBm |
|
Maximum frequency error |
±0.1ppm |
|
Sensitivity |
Cold start: -148 DBM Hot start: -156 DBM Recapture: -160 DBM Tracking: -162 DBM |
|
TTFF |
Cold start: 32 seconds on average |
|
antenna |
GPS ceramic/RF antenna FPC |
